Pneumonia (consolidation)
Infection of the air spaces (air
bronchograms) and/or interstitium of the lung.
Finding:
- Depending upon the amount and distribution of the airspaces involved, this may present as confluent parenchymal (lobar or segmental) opacity or merely patchy opacity.
- If the Interstitium is predominantly involved, it may appear as a reticulonodular pattern.
- Air bronchograms would confirm an alveolar process.
- The lung volume should not be lost (may even be increased).
- Usually all radiographic
abnormalities should disappear after 6 weeks of appropriate antibiotic
therapy. However, pneumonia may
be complicated by abscess or empyema formation.
Examples of Pneumonias and how to
determine location. (look for the silhouette sign…loss of usual visualized
borders.)
Consolidation Pattern
Right Middle Lobe Consolidation
Right Middle Lobe Pneumonia
Right Lower Lobe Pneumonia
Right Lower Lobe Pneumonia, Anterior Segment
Right Lower Lobe Pneumonia, Superior Segment
Right Upper Lobe Pneumonia
Left Lingular Pneumonia
Left Lower Lobe Pneumonia, Anterior Segment
Left Lower Lobe Pneumonia, Posterior Segment
Round Pneumonia
Round Pneumonia
Round Pneumonias are found typically in the
child. Most often the organism is pneumococcus. The pneumonia appears round because
of poorly developed collateral pathways (pores of Kohn and channels of Lambert).
Over time though initially round, it develops into a more consolidative
pattern.
